SPESIFIKASI DUCATI SCRAMBLER

Scrambler Ducati icon
IconScrambler ICON


  • *ENGINE
  •
  • TypeL-Twin, Desmodromic distribution, 2 valves per cylinder, air cooled
    Displacement803 cc
    Bore x stroke88 x 66 mm
    Compression ratio11:1
    Power55 kW (75 hp) @ 8,250 rpm
    Torque68 Nm (50 lb-ft) @ 5,750 rpm
    Fuel injectionElectronic fuel injection, 50 mm throttle body
    ExhaustExhaust system with single stainless steel muffler, aluminium silencer cover, catalytic converter and 2 lambda probes



      • TRANSMISSION
      • Gearbox6 speed
        Ratio1=32/13 2=30/18 3=28/21 4=26/23 5=22/22 6=24/26
        Primary driveStraight cut gears; Ratio 1.85:1
        Final driveChain; Front sprocket 15; Rear sprocket 46
        Clutch
        • CHASSIS
        •
        • FrameTubular steel Trellis frame
          Front suspensionUpside down Kayaba 41 mm fork
          Front wheel travel150 mm (5.9 in)
          Front wheel10-spoke in light alloy, 3.00" x 18"
          Front tyrePirelli MT 60 RS 110/80 ZR18
          Rear suspensionKayaba rear shock, pre-load adjustable
          Rear wheel travel150 mm (5.9 in)
          Rear wheel10-spoke in light alloy, 5.50" x 17"
          Rear tyrePirelli MT 60 RS 180/55 ZR17
          Front brake330 mm disc, radial 4-piston calliper with ABS as standard equipment
          Rear brake245 mm disc, 1-piston floating calliper with ABS as standard equipment

          • DIMENSIONS AND WEIGHT
          • Wheelbase1,445 mm (56.9 in)
            Rake24°
            Trail112 mm (4.4 in)
            Total steering lock35°
            Fuel tank capacity13.5 l - 3.57 gallons (US)
            Dry weight170 kg (375 lb)
            Wet weight*186 kg (410 lb)
            Seat height790 mm (31.1 in) - low seat 770 mm (30.3 in) available as accessory
            Max height1,150 mm (45.3 in) / brake reservoir
            Max width845 mm (33.3 in) / mirrors
            Max length2,100 - 2,165 mm (82.7 - 85.2 in)
            Number of seatsDual seat

            • EQUIPMENT
            • Standard EquipmentSteel tank with interchangeable aluminium side panels, headlight with glass lens, LED light-guide and interchangeable aluminium cover, LED rear light with diffusion-light, LCD instruments with interchangeable aluminium cover, machine-finished aluminium belt covers, 18’’ front, 17’’ rear wheels, under-seat storage compartment with USB socket









    ClassicScrambler CLASSIC

Urban EnduroScrambler URBAN ENDURO
Full ThrottleScrambler THROTTLE

SPESIFIKASI PANIGALE SUPERLEGGERA



Technical Specifications

The 1199 Superleggera is the most exclusive and extreme Ducati ever made.

An unprecedented 200+ horsepower in homologated configuration (205+ with included racing exhaust) and a 166Kg weight ready-to-ride without gas (around the same as a Superbike in full racing trim) give it the best, by far, power to weight ratio of any homologated motorcycle.

Accordingly, Ducati’s test rider Alessandro Valia has obtained with the 1199 Superleggera the best time ever for a street Ducati around the Tuscan Mugello circuit, an incredible 1’54”9.

Engine and Transmission

ENGINE
EngineSuperquadro: L-Twin cylinder, Desmodromic valve actuation, 4 valves per cylinder, liquid cooled
Displacement1,198 cc
Bore X stroke112 x 60.8 mm
Compression ratio13.2:1
Powerexceeds 200 hp (149Kw) @ 11,500 rpm
Torque134 Nm (99 ft-lbs) @ 10,200 rpm
Fuel injectionMitsubishi electronic fuel injection system. Twin injectors per cylinder. Full Ride-by-Wire elliptical throttle bodies
Exhaust2-1-2 system, primary tubes in titanium. Twin titanium mufflers. 2 lambda probes and 2 catalytic converters
TRANSMISSION
Gearbox6 speed
Primary driveStraight cut gears; Ratio 1.77:1
Ratio1=37/15 2=30/16 3=27/18 4=25/20 5=24/22 6=23/24
Final driveChain; Front sprocket Z=15; Rear sprocket Z=41
ClutchHydraulically controlled slipper/self-servo wet multiplate clutch with Superbike configuration

Chassis and Equipment

CHASSIS
FrameMonocoque in magnesium alloy
Front suspensionFully adjustable 43mm USD Öhlins FL 916 fork with TiN treatment, billet fork bottoms and lightweight stress-optimized outer tubes
Front wheel3-spoke magnesium alloy 3.50" x 17"
Front tyrePirelli Diablo Supercorsa SP 120/70 ZR17
Rear suspensionFully adjustable single Öhlins TTX36 shock with titanium spring, with linkage adjustable between progressive/flat. Aluminium single-sided swingarm. Adjustable swingarm pivot.
Rear wheel3-spoke magnesium alloy 6.00" x 17"
Rear tyrePirelli Diablo Supercorsa SP 200/55 ZR17
Wheel travel (front/rear)120 mm (4.7 in) - 130 mm (5.1 in)
Front brake2 x 330 mm semi-floating discs, radially mounted Brembo Monobloc Evo M50 4-piston callipers with ABS, Brembo MCS 19-21 adjustable-ratio front brake master cylinder, remote lever adjuster
Rear brake245 mm disc, 2-piston calliper with ABS
InstrumentationColour TFT display
EQUIPMENT
Riding Modes, Power Modes, ABS, DTC, DQS, EBC, DES, DDA+ w/GPS module, Fully RbW. DWC based on inertial platform. Dedicated buttons for rapid setting of DTC, DWC, EBC. Titanium rods. Carbon fibre parts: fairings, seat base, heel guards, air duct covers, power switch cover, rear shock cover, front and rear mudguards. Titanium bolts.

Dimension and Weight

DIMENSIONS AND WEIGHTS
Dry weight155 kg (342 lb)
Kerb weight without fuel166 kg (366 lb)
Kerb weight177 kg (390 lb)
Seat height830 mm (32.7 in)
Fuel tank capacity17 l (4.5 US gallons)
Number of seatsSingle seat
WEIGHT REDUCTION
ComponentWeight Saved (vs. 1199 Panigale R)
Carbon fibre fairings and assorted pieces-1.0Kg (-2.2lb)
Magnesium alloy Monoscocca mainframe-1.0Kg (-2.2lb)
Carbon fibre rear subframe-1.2Kg (-2.7lb)
Titanium exhaust system-2.5Kg (-5.5lb)
Forged and machined magnesium wheels-1.0Kg (-2.2lb)
Lithium-Ion battery-2.0Kg (-4.4lb)
Custom front fork and rear shock-1.4Kg (-3.1lb)
Superbike pistons-194g (-.4lb)
Crankshaft with tungsten counterweights-396g (-.9lb)
SBK chain and rear sprocket, and various carbon fibre parts, fasteners, and machined-from-billet components-1.3Kg (-2.9lb)
12Kg (26.5lb) overall (wet) weight savings vs. 1199 Panigale R
WARRANTY
Warranty (months)2 years unlimited mileage
Maintenance (km/months)12,000 km (7,500 mi) / 12 months
Valve clearance adjustment (km)12,000 km (7,500 mi) - street use
EMISSIONSEuro 3

DUCATI MONSTER 821 DARK 2015



Technical specification

Engine

Type
Testastretta 11° L-Twin, 4 Desmodromically actuated valves per cylinder, liquid cooled
Displacement
821cc
Bore x Stroke
88 x 67.5mm
Compression ratio
12.8:1
Power
82.4 kW (112 hp) @ 9,250 rpm
Torque
89.4 Nm (65.8 lb-ft) @ 7,750 rpm

Technical data referring to power and torque was measured on an engine test stand at Ducati.
Fuel injection
Electronic fuel injection system, 53mm throttle bodies with full Ride by Wire
Exhaust
Stainless steel muffler and aluminium and cap; lightweight 2-1 system with catalytic converter with 2 lambda probes

Transmission


Gearbox
6 speed
Primary drive
Straight cut gears, ratio 1.85:1
Ratio
1=37/15 2=30/17 3=28/20 4=26/22 5=24/23 6=23/24
Final drive
Front sprocket 15; Rear sprocket 46
Clutch
APTC slipper and self-servo wet multiplate clutch with control cable

Chassis


Frame
Tubular steel Trellis frame attached to the cylinders head
Front suspension
Upside down 43mm forks
Front wheel
10-spoke in light alloy 3.50" x 17"
Front Tyre
120/70 ZR 17 Pirelli Diablo Rosso II
Rear suspension
Progressive linkage with adjustable monoshock. Aluminium double-sided swingarm
Rear wheel
10-spoke in light alloy 5.50" x 17"
Rear tyre
180/60 ZR17 Pirelli Diablo Rosso II
Front wheel travel
130mm (5.1in)
Rear wheel travel
140mm (5.5 in)
Front brake
2 x 320mm semi-floating discs, radially mounted Monobloc Brembo M4-32 callipers, 4-pistons, radial pump with ABS as standard
Rear brake
245mm disc, 2-piston floating calliper with ABS as standard equipment
Instrumentation
LCD display

Dimensions and weight


Dry weight
179.5kg (395.7lb)

Weight data refers to the dry weight of the motorcycle without battery, lubricants and coolants for liquid-cooled models.
Wet weight (KERB)
205.5kg (453lb)

Kerb weights indicate total bike weight with all operating consumable liquids and a fuel tank filled to 90% of capacity (as per EC standard 93/93).
Seat height
Adjustable 785 - 810 mm (30.9 - 31.9)
Wheelbase
1480mm (58.3in)
Rake
24,3°
Trail
93.2mm (3.7in)
Fuel tank capacity
17.5l - (4.6 US gal)
Number of seats
Dual seat

Equipments

Standard Equipment
Riding modes,Power modes, DSP Ducati Safety Pack (ABS + DTC), RbW, passenger handles, ready for anti-theft system and DDA

Warranty


Warranty
24 months unlimited mileage
Maintenance service intervals
15.000km (9.000m)/12 Months
Valve clearance check
30.000km (18,000m)

Emissions and Consumption


Standard
Euro 3
